Goulds 2ED51C0HA 1/2 HP 115 volt 20-foot cord Effluent submersible pump double seal with Sensor Probe

Goulds 2ED51C0HA 1/2 HP 115 volt 20-foot cord Effluent submersible pump double seal with Sensor Probe

Goulds 2ED Technical Brochure
Goulds 2ED Installation Manual
Goulds 2ED Drawings

Specifically designed for the following uses:

-Farms
-Motels
-Hospitals
-Trailer courts
-Schools
-Industry
-Effluent systems

Features and Benefits

Impeller: Cast iron, semi-open, non-clog with pump-out vanes for mechanical seal protection. Balanced for smooth operation. Silicon bronze impeller available as an option.
Casing: Cast iron volute type for maximum efficiency. 2″ NPT discharge.
Dual Mechanical Seals Lower: Silicon Carbide vs. Silicon Carbide sealing faces. Stainless steel metal parts, BUNA-N elastomers. Upper: Carbon vs. ceramic sealing faces. Stainless steel metal parts, BUNA-N elastomers.
Seal Sensor Probe: Located in oil-filled chamber. If pumpage should begin to leak past lower seal it indicates to pump control panel a fault has occurred. Requires optional Seal Fail Circuit in the control panel.
Shaft: Corrosion resistant, stainless steel. Threaded design. Lock nut on all models to guard against component damage on accidental reverse rotation.
Fasteners: 300 series stainless steel.
Capable of running dry without damage to components.
Designed for continuous operation when fully submerged.
