Goulds WS0518B 1/2 HP 208 volt 20-foot cord Model 3886 Sewage Pump

Goulds WS0518B 1/2 HP 208 volt 20-foot cord Model 3886 Sewage Pump Capacitor Start Motor non-automatic

Goulds WS-B 3886 Technical brochure

Goulds WS-B 3886 Installation manual

Designed for residential and light commercial sewage, greywater and septic applications

Heavy-Duty Cast Iron Housing & Volute

Robust design provides maximum durability and efficiency

FEATURES

Impeller: Cast iron, semi-open, dynamically balanced, non-clog with pump out vanes for mechanical seal protection. Optional Silicon bronze impeller available.

Casing: Cast iron volute type for maximum efficiency. Designed for easy installation on A10-20 guide rail or base elbow rail systems.

Mechanical Seal: SILICON CARBIDE VS. SILICON CARBIDE sealing faces for superior abrasive resistance, stainless steel metal parts, BUNA-N elastomers.

Shaft: Corrosion-resistant stainless steel. Threaded design. Locknut on all models to guard against component damage on accidental reverse rotation.

Specifically designed for the following uses:

• Homes

• Sewage systems

• Dewatering/Effluent

• Water transfer

SPECIFICATIONS

Pump

• Solids handling capabilities: 2" maximum

• Discharge size: 2" NPT

• Capacities: up to 185 GPM

• Total heads: up to 38 feet TDH

• Temperature: 104°F (40°C) continuous, 140°F (60°C) intermittent

MOTORS

• Fully submerged in high grade turbine oil for lu­brication and efficient heat transfer. All ratings are within the working limits of the motor.

• Class B insulation

Single phase (60 Hz):

• All single phase models feature capacitor start motors for maximum starting torque.

• Built-in overload with automatic reset.

• SJTOW or STOW severe duty oil and water resis­tant power cords.

• ¹⁄3 – 1 HP models have NEMA three prong ground­ing plugs.

Three phase (60 Hz):

• Class 10 overload protection must be provided in separately ordered starter unit.

• STOW power cords all have bare lead cord ends.

• Bearings: Upper and lower heavy duty ball bearing construction.

• Designed for Continuous Operation: Pump ratings are within the motor manufacturer's recommended working limits, can be operated continuously with­out damage when fully submerged.

• Power Cable: Severe duty rated, oil and water resis­tant. Epoxy seal on motor end provides secondary moisture barrier in case of outer jacket damage and to prevent oil wicking. Standard cord is 20'. Optional lengths are available.

• Motor Cover O-ring: Assures positive sealing against contaminants and oil leakage.
