Barnes PGPP2022A 2 HP 230v Automatic Sewage Grinder Pump 110646

Barnes PGPP2022A 2 HP, 230 volt 110646 Automatic Sewage Grinder Pump with float switch

Barnes Crane PGPP Brochure
Barnes Crane PGPP Installation Manual

The PGPP Series Grinder Pump is designed to pump residential and light commercial sewage in a slurry.

PGPP2011 is ideal for pressure sewer and high-head applications.

Barnes PGPP Series Submersible Grinder Pump Features:

Cast iron construction for corrosion resistance

NEMA L- Single Phase Torque Curve, Oil-Filled, Squirrel Cage Induction Motor.

Single Phase has Capacitor Start/Capacitor Run.

Upper Bearing: Single Row, Ball, Oil Lubricated,
Radial Load. Lower Bearing:
Single Row, Ball, Oil Lubricated, Radial & Thrust Load.

Mechanical seal: Silicon-Carbide/Silicon-Carbide/Buna-N Hardware - 300 Series stainless steel.

Impeller: Cast Iron ASTM A-48, Class 30.

Barnes "Slicerator" Cutting Mechanism to Increase Torque for Preventing Clogging.

1-1/4" NPT Female threaded connection, Vertical, Bolt-On Flange.

Temperature Rating: 160°F (71°C) Intermittent.

Carton dimensions: 13” X 12” X 27” 86 LB
